KWH Weatherproof Enclosure

Product Model  : KWH Series

Metal Enclosures
Material : Electro-Galvanized

(EG) Sheet
Color : RAL 7035 (Light Grey)
Thickness : 0.8mm to 1.0mm
Ingress Protection Rating : IP14 to IP54
Availability     : Yes



Download Catalog :

Download Drawing :

Categories
FacebookXPinterestRedditDeliciousLinkedinWhatsappTelegramEmail

– Product Table –

KWH Enclosure Single Phase Dimension
60A Single Phase Meter – 1WPA (Weatherproof)
No. Part No. Body Dimension (mm)
Width (W) Height (H) Depth (D)
1 KWH-1WP 280 430 160
2 KWH-1WP-H 350 290 160
3 KWH-1WP 280 430 160
4 KWH-1WP 280 430 160
5 KWH-1WP 350 290 160

KWH Enclosure Three Phase Dimension
60A Three Phase Meter – 3WPA (Weatherproof)
No. Part No. Body Dimension (mm)
Width (W) Height (H) Depth (D)
1 KWH-3WPA 330 590 180
2 KWH-3WPA-D 330 590 180
3 KWH-3WPA-N 330 590 180
4 KWH-3WPA-ND 330 590 180
5 KWH-3WPA-BM 330 590 180
100A Three Phase Meter – 3WPB (Weatherproof)
No. Part No. Body Dimension (mm)
Width (W) Height (H) Depth (D)
1 KWH-3WPB 330 590 180
2 KWH-3WPB-D 330 590 180
3 KWH-3WPB-N 330 590 180
4 KWH-3WPB-ND 330 590 180
